Trojan Battery
Golf and Utility Vehicles
Trojan Battery is the most commonly used Deep Cycle Batteries in almost all the products of Golf car / Transportation vehicle in the industry today.
Built to deliver superior performance, durability and reliability, these batteries utilize the highest quality components and meet the challenges of the toughest, hilliest courses in the world.
- Reliant™ AGM with C-Max Technology™ is engineered with an advanced feature set that provides outstanding sustained performance and total energy output, delivering the exceptional quality and reliability Trojan batteries are known for.
- Trojan’s proprietary Maxguard® T2 Separator and exclusive Alpha Plus® Paste with T2 Technology™ team up to increase battery life, extend run time and decrease maintenance.
- Offering durability and reliability to deliver high performance on and off the course
| Models |
|
|
|
|---|---|---|---|
| Type | T-105 | T-875 | T-1275 |
| Weight | 62 lbs (28 Kg) | 63 lbs (29 Kg) | 82 lbs (37 Kg) |
| Length | 10 3/8" (264 Mm | 10 3/8" (264 Mm) | 12 7/8" (327 Mm) |
| Width | 7 1/8" (181 Mm) | 7 1/8" (181 Mm) | 7 1/8" (181 Mm) |
| Height | 10 7/8" (276 Mm) | 10 7/8" (276 Mm) | 10 7/8" (276 Mm) |
| Capacity Minutes @25Amps | 447 | 295 | 280 |
| Capacity Minutes @75Amps | 115 | 117 | 102 |
| Capacity Amp-Hours @ 5Hrs | 185 | 145 | 120 |
| Capacity Amp-Hours @ 20Hrs | 225 | 170 | 150 |
| Voltage | 6 V | 8 V | 12 V |
| Terminal | LPT, WNT,AP, UT, LT | LPT, WNT, AP | LPT |
